這種十二股纜繩是由高分子量聚乙烯纖維制造，它是由各6個分別是“S”和“Z”捻向的繩股交織而成，這樣就使繩子不會發生旋轉，這種纜繩是空心編織的。
12-Strand Rope is a torque-free 8-strand & 12-strand single braided rope that size for size and is as strong as steel all of above ,making it an excellent wire rope replacement. At only 1/8th the weight of wire, it is a safe and efficient solution for all marine applications where wire is traditionally used. The combination of UHMWPE provide abrasion and tension fatigue resistance for superior wear. It is easily spliced and inspected.
主要性能 >> Main performance
|
◎ 材料：超高分子量聚乙烯纖維
◎ 結構：八、十二股編織
◎ 應用：海洋、漁業
◎ 顏色：黃色（其他顏色根據要求）
◎ 比重：0.975，浮水
◎ 熔點：145℃
◎ 耐磨性：非常好
◎ 防紫外線：好
◎ 使用環境：最大70℃
◎ 耐化學腐蝕性：非常好
◎ 干濕性能：濕強度=干強度
◎ 使用范圍：漁業、海洋工程、系泊
◎ 每卷長度：220m
◎ 結強力損失：10%
◎ 重量和長度誤差：5%
◎ 最小破斷力：根據ISO2307標準說明
◎ 如果需要其他尺寸，可以根據客戶要求定制
|
◎ Material: UltraHigh Molecular Weight Polyethylene
(UHMWPE)
◎ Construction: 12 strand braided
◎ Treatment: Marine finish, Offshore
◎ Standard Color: Yellow (also available by special
order in red, green, blue, orange and so on)
◎ Approx. Spec. Density 0.975 floating
◎ Melting Point: 145℃
◎ Abrasion Resistance: Excellent
◎ U.V.resistance: Good
◎ Temperature resistance: 70℃ max continuous
◎ Chemical resistance: Excellent
◎ Dry & wet conditions: Wet strength equals dry strength
◎ Range of use: Fishing, off-shore installation, mooring
◎ Coil length: 220m
◎ Spliced strength: ±10%
◎ Weight and length tolerance: ±5%
◎ MBL= Minimum Breaking Load conform ISO 2307
◎ Other sizes available upon request
|
